Description
IronRidge XR-1000 Mill Finished Rail 204" (17FT)
XR-1000-204M is a specific model of structural solar panel mounting rail manufactured by IronRidge. It is part of the XR1000® rail family, which is engineered for heavy-duty solar installations with high load requirements and long span capabilities — commonly used in commercial or robust residential solar array projects. The “204M” suffix indicates a 204-inch (17-foot) rail length with a mill (unfinished) aluminum finish. These rails serve as the backbone of a racking system, securing solar modules and supporting them against wind, snow, and other environmental forces.
- Length: ~204″ (17 feet / ~5.18 m)
- Material: 6000‑series aluminum alloy
- Finish: Mill (unfinished aluminum)
- Profile: Curved I‑beam style for strength and resistance to bending/twisting
- Weight: 17.4 lbs
-
Downloads
Datasheet
✔️ Datasheet
Quick Installation Guide
No quick installation guide. Email support@solux.energy for file request.
Warranty
No warranty available. Email support@solux.energy for file request.
Download Spec Sheet
Designed in compliance with applicable BCI, DIN, BS and IEC standards. Tested in compliance to BCI and IEC standards.
