Description
Wiring Box, Inverter
The PVI-50-60TL-WB-TGO is a dedicated wiring box for the PVI-50TL-480 and PVI-60TL-480 transformerless string inverters. It provides fused PV string inputs and includes a built-in Tigo transmitter for module-level rapid shutdown when used with compatible Tigo devices.
Specifications:
- Manufacturer Part Number: PVI-50-60TL-WB-TGO
Mechanical:
- Maximum DC Voltage: 1000 VDC
- Fused Positions: 15
- MPPT Configuration: 5 inputs per MPPT × 3 MPPTs
- Standard Fuse: 20A
- Accepted Fuse Sizes: 20A / 25A / 30A
- Fuse Polarity: Positive only
- Rapid Shutdown: Tigo integrated transmitter
- RSD Compatibility: Tigo TS4-A-F v6.7+ and TS4-A-2F
- Inverter Compatibility: PVI-50TL-480 / PVI-60TL-480
- Enclosure: NEMA Type 4X
-
