  • A white modular solar power system with four stacked rectangular inverters on top and a separate white control or battery box below, connected by thick black cables, shown on a light gray studio background.
1 3

SolarEdge SE-TRI-US00IBNW4 Synergy Manager 50kW/100kW/110kW/120kW

$3,726.98 USD
$3,726.98 USD
Sale Sold out
Shipping calculated at checkout.

Key Features:

✔️Three-phase Synergy Manager
✔️Single DC input
✔️Fuse-less design
✔️Integrated Rapid Shutdown (RSD)
✔️Supports high-power commercial SolarEdge systems
✔️Designed for 3 Synergy Units per inverter
✔️Bracket mounting
✔️NEMA 3R enclosure

All orders are subject to product availability. We will notify you if an item is unavailable or delayed within 24-48 business hours.
Secure checkout with
  • Ach Direct Debit
  • American Express
  • Apple Pay
  • Diners Club
  • Discover
  • Google Pay
  • Mastercard
  • PayPal
  • Shop Pay
  • Visa

Visit our Shipping Policy and Returns Policy page for further details

 View Product Details

  • Description

    Three Phase Synergy Manager, RSD, Single Input (Fuse-less), configured to 50kW/100kW/110kW/120kW

    The SE-TRI-US00IBNW4 is a SolarEdge Three-Phase Synergy Manager used as part of a large commercial SolarEdge inverter system. It manages the DC input and works with three Synergy Units to form high-power systems rated at 50 kW, 100 kW, 110 kW, or 120 kW depending on the configuration. It is a single-DC-input, fuse-less, RSD-enabled Synergy Manager.

    Specifications:

    • Model/Part Number: SE-TRI-US00IBNW4
    • Product Type: Three-Phase Synergy Manager
    • Input: Single DC input
    • AC voltage: 208/480 V
    • Power configurations: 50 kW @ 208 V; 100/110/120 kW @ 480 V
    • Phase: 3-phase
    • Mounting: Bracket
    • Enclosure: NEMA 3R
    • System configuration: 3 Synergy Units per inverter

  • Resources

    Datasheet

    ✔️ Download Datasheet

    Quick Installation Guide

    ✔️ Download Quick Installation Guide

    Warranty

    ✔️ Download Warranty

Download Spec Sheet of SolarEdge Three Phase Synergy Manager
