The smart Solution for medium-sized commercial enterprises
The Sunny Tripower X 60 sets new standards for commercial PV systems. Thanks to a power output of up to 60 kW, 5 independent MPP trackers, and an integrated system manager, it enables high energy yields and efficient use of high-performance, bifacial PV modules. It is a future-proof solution for commercial applications, thanks to its innovative design and easy commissioning.
With its compact design, weighing 50.5 kg and optimized for wall-mounted installation, the Sunny Tripower X 60 saves space and enables fast and hassle-free setup, even by small teams. The Roof Mount Kit, which allows for horizontal installation, offers additional flexibility in system design. Commissioning is carried out via an intuitive User Interface, and DC wiring is completely tool-free. Using SMA Speedwire, the Sunny Tripower 60 can be integrated seamlessly into the SMA Commercial Energy Solution, including battery storage systems, EV charging infrastructure, and energy management. Centralized control via Sunny Portal powered by ennexOS, enables dynamic management of active and reactive power to optimize grid stability and efficiency.
-
Description
Specifications:
- Model: STP 50-US-80 (480V)
- Series: Sunny Tripower-X-xx-US-80
- Manufacturer: SMA
Mechanical:
- Type: Commercial Grid-Tie Inverter
- Operating Temperature Range: -25°C to +60°C (−13°F to +140°F)
- Maximum Relative Humidity (Non-Condensing): 100%
- Mounting Type: Vertical rack / wall mount to 20° from horizontal
- DC Connection / AC Connection: Staubli MC4 / Screw Terminals
- Dimensions (W x H x D): 26.8 x 36.6 x 13.1 in (680 x 930 x 332 mm)
- Device Weight: 117 lbs (53 kg)
- Audible Noise Emission: 55 dB(A)
- Topology / Cooling Concept: Transformerless / OptiCool (forced convection, variable speed fans)
- Enclosure Protection Rating: Type 4X (as per UL 50E)
- Corrosive Classification: C5
- Shipping Method: Freight
- Warranty: 10 Years (Standard) / 15 and 20 Years (Optional)
-
