SMA Data Manager M Lite - Monitors up to 5 devices / 30kVA, powered by ennexOS

SMA RGM05KIT-US-10 Revenue Grade Meter Kit For Use w/ Cellular LTE Modem

Accurate & Versatile - ANSI C12.20 revenue grade energy production monitoring provides a high level of accuracy
Perfect Alignment - Designed for integration with Power+ Solution and ultra-compact DIN rail mounted meter kit mounts inside the Sunny Boy inverter
Plug & Play - Quick and easy setup. Prewired and preassembled kit reduces installation time with

Technical Specifications

• Compatible Inverter Models: MA SBx.x-1SP-US-40
• Compatible Inverter Firmware: 2.04.74.R or later
• ANSI C12.20 Measurement Accuracy: 0.5%
• Operating Voltage Range: 120 - 277 VAC
• AC Frequency Range: 45 - 65 Hz
• Rated CT Current: 50 A
• Grids Supported, Single Phase 2-Wire: 208 V WYE, 208 V Delta (no neutral), 240 V Split phase, 240 V Delta (no neutral)
• Dimensions (H x W x D): 00 x 100 x 85 mm / 3.94 x 3.94 x 3.35 in
• Weight: 0.4 kg / 0.88 lbs
• Temperature Range (Operating): -25°C to +60°C / -13°F to +140°F
• Protection Rating: NEMA 1 (IP40)
• Mounting Type: DIN rail (included in kit)
