Jinko EAGLE JKM425N-54HL4-B 425Watt 108 Half-Cell Black on Black Monocrystalline Solar Panel

Jinko JKM425N-54HL4-B

• The JKM425N-54HL4-B is a premium Jinko Eagle solar module that features N-Type TOPCon technology. This powerful unit is engineered to maximize output on rooftops, producing 425W of power. Its Black Back Sheet (BoB) and 35mm black frame ensure a sleek look. The technical specifications, including the 108 N type 1/2 cells, 1000VDC capacity, and 25A fuse, are validated by its 398.1 PTC rating and robust 25/30 warranty. The module is easily connected using the MC4 1400mm (55" PV wire) leads, providing reliable, high-efficiency power.

• Product Performance

  Rated Power


  Rated Power per Cell


  Efficiency


  Power Tolerance


  Temperature Coefficient


  Resiliency

  425W


  422W


  21.67%


  3%


  PMax: -0.29 | Voc: -0.25


  ✔️ Snow
  ✔️ Wind
  ✔️ Hail
  ✔️ Fire







  Power (measured in watts) and efficiency (how well panels convert sunlight to electricity) are some of the most common metrics used to compare solar panel products. While they are not the only means of comparison, they are important determinants in how much electricity you can produce with a solar panel system. Metrics like power tolerance and temperature coefficient are also important ways to analyze the potential performance of solar panels under the different conditions they will experience over their lifetime. Learn how panels from different manufacturers stack up against one another in our updated article about the best solar panels on the market.

• Warranty Information

  ✔️ Output Warranty Term: 30 years
  ✔️ Output Decline: 0.4%
  ✔️ Output at End of Warranty Term: 87.4%
  ✔️ Materials Warranty Term: 25 years

  Solar panels generally come with an output warranty covering the energy production of the panel, and a materials warranty protecting you against undue wear and tear on your equipment. Learn more about solar panel warranties.

• Physical Characteristics

  ✔️ Cell Type: Monocrystalline
  ✔️ Panel Dimensions: 1722mm x 1134mm x 35mm
  ✔️ Cell Count: 108
  ✔️ Connector Type: Staubli MC4

  The physical characteristics of a solar panel have an impact on the product's performance. For example, metrics like efficiency and wattage are based on the type, size, and number of solar cells used in a panel.

• Certifications

  ✔️ Certifications Received: IEC 61215, IEC 61730, UL 1703, ISO9001, ISO14001

  Organizations like the International Electrotechnical Commission (IEC) and Underwriters Laboratories (UL) create national and international standards for photovoltaic solar panels to ensure any products on the market meet certain specifications for safety and reliability reasons.
