Hoymiles HMS Microinverter 2000-4T-208

Hoymiles Microinverter  HMS 2000-4T-208

• High-powered C&I efficiency in a 4-in-1 design. The HMS-2000-4T-208 is a specialized hoymiles microinverter engineered specifically for North American 208V Three-Phase Delta networks. By supporting four high-wattage modules (up to 670W+) with a single unit, it delivers commercial- ale power density while maintaining the granular optimization of an MLPE system.
•  Native 3-Phase Delta Engineering Unlike residential units that require phase balancing, this hoymiles microinverter is natively designed for North American 208V 3-Phase Delta networks. Its high 1.5:1 DC/AC ratio and 16A input current support the latest generation of ultra-high-powered 600W+ modules.
• Sub-1G Stability for C&I Sites Recognizing the interference-heavy nature of commercial environments, Hoymiles utilizes a Sub-1G wireless solution. This lower-frequency communication offers superior range and wall penetration compared to standard 2.4GHz WiFi or Zigbee, ensuring stable data transmission to the DTU-Pro-S gateway.

• Rapid Shutdown & Isolation Built for industrial safety, the unit features a galvanically isolated transformer and is fully NEC 690.12 rapid shutdown compliant. It meets stringent North American standards, including UL 1741 SB and IEEE 1547-2018, providing a bankable solution for strictly regulated utility territories.

• Cost-Effective Reliability The 4-in-1 design significantly reduces "points of failure" and balance-of-system (BOS) costs compared to individual microinverters. With an IP67 (NEMA 6) rating and a 25-year performance roadmap, it is built to operate at full power in temperatures up to +65°C.

Technical Specifications:

• Commonly used module power (W): 400 to 670+
• Maximum input voltage (V): 65
• MPPT voltage range (V): 16–60
• Minimum/Maximum start-up voltage (V): 22/60
• Maximum input current (A): 4 × 16
• Maximum input short circuit current (A): 4 × 25
• Number of MPPTs: 2
• Number of inputs per MPPT: 2
• Rated output power (VA): 2000
• Maximum continuous output power (VA): 1918
• Maximum continuous output current (A): 5.33
• Nominal output voltage (V): 208
• Nominal output voltage range (V)1: 183-228
• Nominal frequency/range (Hz)1: 60/55-65
• Total harmonic distortion: < 3%
• Maximum units per 10 AWG branch2: 4
• Maximum units per 12 AWG branch2: 3
• CEC peak efficiency: 96.50%
• Nominal MPPT efficiency: 99.80%
• Night power consumption (mW): < 50
• Dimensions (W × H × D): (326 × 222 × 40.6 mm)
• Weight: (lbs) 12.79 (5.8 kg)
• Enclosure rating: Outdoor-IP67
