IronRidge GM-DB3-TB01-M1 Diagonal Brace 2.5" Square Tube, 87.0" LG (For 3" Pipe)

$245.18 USD
$245.18 USD
Sale Sold out
Shipping calculated at checkout.

Key Features:

✔️ North-South Structural Stabilization: Mounts diagonally between north and south vertical leg pairs to provide cross-bracing and handle lateral wind uplift and seismic loading.
✔️ Shorter Length Profile: The 87" brace tube (TB01) accommodates narrower pier spacing or lower tilt angle geometries on 3" schedule pipe substructures compared to the longer 105" version (TB02).
✔️ Sleeve & Hardware Integration: Connects directly into IronRidge 3" Diagonal Brace Sleeves (GM-DB3-SLV01-M1) and brace hardware kits (GM-DB-HW01-M1).
✔️ High-Strength Aluminum: Manufactured from structural 6061-T6 mill-finish aluminum for high strength-to-weight performance and long-term weather resistance.
