IronRidge GM-BRC-003 Bonded Rail Connector: Secure Ground Mount Assembly
The IronRidge GM-BRC-003 is a heavy-duty bonded rail connector that locks horizontal cross pipes securely to XR100 or XR1000 structural rails in ground-based solar installations. Built for industrial performance, this IronRidge rail connector provides the structural grip needed to keep a solar frame from shifting under heavy wind or snow loads. As the hardware is tightened, integrated teeth pierce the metal surface to create a permanent electrical bond. This smart design handles both the physical connection and safety grounding in a single step, saving installers time and reducing the need for extra copper wires. It pairs seamlessly with standard solar mounting hardware to streamline large-scale arrays.
Key Technical & Physical Specs
- Manufacturer Part Number: GM-BRC-003
- Manufacturer: IronRidge
- Finish: Mill Finish
- Quantity: 1 set per unit
- Weight: 1.170 lb
- Manufacturer Part Number: GM-BRC-003
-
Downloads
Datasheet
✔️ Datasheet
Quick Installation Guide
Warranty
No warranty file resource available. Email support@solux.energy for file request.
