FranklinWH Split Current Transformer Kit for Aux Connection, A/Gate Meter

FranklinWH Split Current Transformer Kit for auxillary connection with the built-in aGate meter. Accuracy 3%. Package contains two 200A/40mA CTs, one splitter terminal block, 15m wire

FranklinWH ACCY-CT200V1-US Split Current Transformer Kit is an auxiliary current-monitoring accessory designed for use with the built-in meter of the FranklinWH aGate. It enables accurate measurement of power flow in applications where the aGate’s internal current transformers cannot directly monitor certain sub-panels or loads. The kit uses non-contact current transformers to safely convert high electrical current into a measurable signal for the Franklin Home Power system.

The kit includes two 200A/40mA split-core current transformers, one splitter terminal block, and 15 meters of wiring, with an accuracy of ±3%

Technical Specifications:

• Manufacturer Part Number: ACCY-CT200V1-US
• Product Type: Split Current Transformer (CT) Kit
• Application: Auxiliary connection to the built-in aGate meter
• Current Rating: 200 A
• Output Current: 40 mA
• Metering Accuracy: ±3%
• Clamp Opening Diameter: 0.94 ± 0.02 in (24 ± 0.5 mm)
• CT Type: Split-core / non-contact current transformer
• Lead Cable: Twisted-pair, black & white
• Cable Length: 50 ft (15 m)
• Operating Temperature: -40°F to 185°F (-40°C to 85°C)
• Ingress Protection: IP30 / NEMA 1
• Splitter Terminal Block: 1 included
• Included Wiring: 15 m
• Connection: Auxiliary metering connection to FranklinWH aGate
• Sensing Method: Magnetic-induced current / non-contact measurement
• CT Weight: Approx. 0.66 lb (300 g)
