Enphase BRK-20A-2P-240V-B-10 Circuit Breaker 2 pole, 20A, 10kAIC, BR220B for Enpower
The Enphase BRK-20A-2P-240V-B-10 is a 20A, 2-pole circuit breaker based on the Eaton BR220B, rated at 240 V and 10 kAIC. It is designed for use in Enphase IQ System Controller and IQ Combiner applications, providing circuit protection for compatible photovoltaic (PV), battery, and backup-energy-system circuits.
Technical Specifications:
- Manufacturer: Enphase Energy / Eaton
- SKU: BRK-20A-2P-240V-B-10
- Product Type: Thermal-magnetic circuit breaker
- ANumber of Poles: 2-pole
- Current Rating: 20 A
- Voltage Rating: 120/240 VAC
- Nominal System Voltage: 240 VAC
- Interrupt Rating: 10 kAIC
- Trip Type: Common trip
- Mounting: Plug-on
- Wire Size: #14–4 AWG Cu/Al
- Certification: UL 489
- Compatible Load Centers: Eaton Type BR loadcenters
- Product Dimensions: 3 in L × 2 in W × 3 in H
- Product Weight: 0.5 lb (approx. 0.23 kg)
-
