Description
Enphase 175A 2-Pole 240V Main Circuit Breaker (BRK-175A-2P-240V)
The Enphase 175A 2-Pole 240V Main Circuit Breaker (BRK-175A-2P-240V) is a heavy-duty main disconnect circuit breaker engineered for Enphase IQ Combiner and System Controller enclosures, as well as compatible load centers. It provides overcurrent protection and main feed isolation for 240 VAC residential solar and energy storage systems.
Featuring a high short-circuit interrupting rating of approximately 25 kAIC, this 2-pole breaker handles continuous currents up to 175 Amps across 120/240 V AC split-phase power. It protects main service feeders and internal busbars against high-level fault currents.
Technical Specifications:
- Max Current: 175 A
- Ampere Interrupting Capacity: 25 kAIC
- Poles: 2 Poles
- Input Current: 175 A
- Power Output: 475 Watts
- Voltage Rating: 120/240 V AC
- Interrupting Capacity: ~25 kAIC (short-circuit rating)
- Shipping Weight: 3.0 lb
- Shipping Dimensions: 6 x 3 x 3 in
-
