ACCESSORY FUSE BYPASS KIT PVI-25TL-208 PVI 50/60TL-480

ACCESSORY FUSE BYPASS KIT PVI-25TL-208 PVI 50/60TL-480

The FUSEBYPASS-PVI-25-60TL is a DC fuse bypass kit designed for Yaskawa Solectria PVI-25TL through PVI-60TL series commercial solar inverters. It allows multiple DC PV inputs to be externally combined before connection to the inverter, bypassing the inverter's individual input fuses and simplifying the DC input configuration.

Specifications:

• Manufacturer Part Number: FUSEBYPASS-PVI-25-60TL
• Product Type: Fuse Bypass Kit

Mechanical:

• Component Type: DC fuse bypass terminal/accessory kit
• Kit Contents: 6 pieces for one compatible inverter
• Mounting/Installation: Installed inside the inverter wiring box
• Input Terminal Sets: 3 sets
• Bypass Terminal Torque: 14 in-lb (1.6 N·m)
• DC Input Cable Torque: 50 in-lb (6.0 N·m)
• Provided Hardware Torque: 16 in-lb (1.8 N·m)
• Approx. Dimensions: 3 × 2 × 0.13 in (7.62 × 5.08 × 0.33 cm)
• Shipping Weight: 15 lb (approximately 6.8 kg)
