Rolls Surrette R24-76LFP FT 76 Ah Lithium Battery

Rolls Surrette R24-76LFP FT 25.6V 76Ah Lithium Iron Phosphate Battery

The Rolls Surrette R24-76LFP FT is a high-density 25.6V 76 Ah (1.95 kWh) Lithium Iron Phosphate (LiFePO4) battery engineered for off-grid renewable energy and telecom power back-up applications. Featuring a slim front-terminal enclosure layout, this battery provides easy front-access wiring for compact alignment inside standard 19-inch and 23-inch equipment racks.

Equipped with an internal Battery Management System (BMS), the safe LiFePO4 chemistry provides long cycle life, thermal stability, and deep discharge capability without maintenance.

Safety

• Certificate / Compliance: UL Recognized – UL 1642
• Safety Standard: IEC 62133 - Occupational Health & Safety
• Transportation: UN 38.3 - Batteries, wet, non-spillable
• Battery Standard: ISO 9001 - Quality management

Technical Specifications:

• Weight: 17kg / 37.5 lbs
• Length: 552 mm / 21.73"
• Width: 110 mm / 4.33"
• Chemistry: LiFePO₄
• Nominal voltage: 24 V
• Rated capacity: 76 Ah
• Rated energy: 1.95 kWh
• Terminal type: F12 (M8)
• Series: Rolls R-Series
